2. Angi 50 CNG compressor's 4000 hours ( Sold) more coming soon

2. Angi 50 CNG compressor's 4000 hours ( Sold) more coming soon

Available quantity: 2

orCall +1 773-960-5642


2 Angi NG50E Compressors Removed working with manuals from a government site...

2 available low hours 3682 and 4300

Compressor type Air-cooled, pressurized crankcase, lubricated, 4-stage, V-type, reciprocating Maker/Model ANGI - Model NG50E Capacity @ rated psig inlet 50 SCFM @ 9 psig inlet Inlet Pressure Range 5-13 PSIG

Maximum Delivery Pressure 4500 PSIG Speed 900 rpm Number of Stages 4 Number of Cylinders 4 Oil Capacity 10 Qts. Compressor Lubrication Crankcase Splash lube, with pressurized lube circuit to crankshaft bearings, connecting rod bearings, and piston pins Oil Pump Reversible positive displacement pump driven off crank. Oil Pressure 25 PSIG (20 PSIG shutdown) Drive Method Multi-groove V-Belt drive Driver Prime Mover TEFC AC squirrel cage electrical motor (Class I Div II – Std, Class I Div I - Optional) Maker / Model WEG Premium Efficiency or equal Electrical Specification Rated Voltage 460 V, 60 Hz Full Load Amperage 48 Amps (50 SCFM), Horsepower 40 hp (50 SCFM), Speed 1800 rpm Motor starting method Direct full voltage starting by on-skid motor starter (std)

CNG Calumet 773-960-5642


ModelAngi 50 job #20537 and job 0526
